Ceisum实时获取后台数据 实时更新实体位置信息且实现实体转向功能

数据科学与大数据 来源： 网络 编辑：小编 更新时间：2024-11-28 17:45:10 浏览量：35

用定时器模拟实时获取后台数据 当取到数据后实体同时移动到目标位置 这种方式不再与Cesium时间关联

实现效果：每秒新增一个坐标；每秒实体运动到相应正确位置且实现实体转向功能

PS：该方法实体经纬度超过正负180，90时需进行坐标计算转为正负180,90范围内的坐标后实体转向才正常；本文未进行处理


二维展示

多个实体运动：实时加载数据 更新位置信息且实体转向




实时更新雷达位置

var viewer = new Cesium.Viewer("cesiumContainer", { shouldAnimate: true, }); var i = 30.; var a = 20; var b=118.007; var position=[b,i,0]; var CircleLineBox=[]; var realTimeClData=setInterval(function() { if(CircleLineBox){ CircleLineBox.forEach(item=>{ viewer.entities.remove(item) }) CircleLineBox=[] } for (var i = 0 ; i < 5; i++){ position[0]+=10.001*Math.random(); position[1]+=10.001*Math.random(); //viewer.entities.removeAll(); var circle=viewer.entities.add({ position: Cesium.Cartesian3.fromDegrees(position[0],position[1]),//以度为单位 ellipse : { semiMinorAxis :,//椭圆的短长轴的长度 以米为单位 semiMajorAxis :, // height: itemParam.Circle.Altitude,//椭球上方的高度（以米为单位) material : Cesium.Color.RED.withAlpha(0.5) } }); CircleLineBox.push(circle) }; }, 2500); Sandcastle.addToolbarButton('清除计时器', function() { clearInterval(realTimeClData); });

cesium实时更新数据实现实体运功

 cesium在二维地图中移动实体

Cesium基于czml的model模型转向

Cesium基于czml billboard的模型转向

 Ceisum实时获取后台数据 实时更新实体位置信息

到此这篇Ceisum实时获取后台数据 实时更新实体位置信息且实现实体转向功能的文章就介绍到这了,更多相关内容请继续浏览下面的相关推荐文章，希望大家都能在编程的领域有一番成就！
